Rich Solar | MEGA 410 | 410 Watt Solar Panel | Premium Grid-tie or Off-grid Solar Panel for Residential, Commercial, Agriculture | 25-Year Output Warranty | UL Certified
Overview
PALLET SHIPPING ONLY!
The MEGA 410 maximizes power generation while minimizing space, equipment necessities, and cost by providing premium solar generation for off-grid systems. With the ability to generate 410W with 24V, the MEGA 410 can generate renewable energy and reduce electricity bills for any residential, agricultural, or commercial solar systems. Its anodized aluminum frame and tempered glass make it withstand any environment you put it in.
Features
- 10-busbar solar cell configuration
- Mono PERC Technology
- Lightweight anodized aluminum frame
- High Transmission, AR (anti-reflective) Coated Tempered Glass
- Plug-and-play junction box
- Industry-standard quick-connect cables work in series or parallel
- Certified to withstand challenging environmental conditions
- Excellent low-light performance on cloudy days, mornings, and evenings
Installation
- Easy installation and handling for various applications (high-end off-grid and mobile applications)
- Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts, and tilt mounts
- Compatible with on-grid and off-grid inverters
Warranty
- 25-year output warranty
- 10-year workmanship warranty
Build-In Components
- 410W monocrystalline solar panel
- Panel leads (pair): 2 feet each
- IP65-rated waterproof junction box
- IP67-rated waterproof solar connectors
- Bypass diodes built into the junction box
Specification
ATTRIBUTE | VALUE |
Maximum Power(Pmax) | 410W |
Maximum Power Voltage(Vmp | 31.3V |
Maximum Power Current(Imp) | 13.1A |
Open Circuit Voltage(Voc) |
37.5V
|
Short Circuit Current(Isc) | 13.8A |
Maximum System Voltage(Vmax) | 1500VDC |
Temperature Range | -40°F ~ 185°F |
Max Series Fuse Rating | 25A |
Weight | 45.2 lb |
Dimensions | 67.9 x 44.6 x 1.2 in |
