Epoch Batteries | 24V 230Ah V2 Elite Series | Heated & Bluetooth & Victron Comms LiFePO4 Battery (PREORDER)

Overview

PRE-ORDER ETA JAN 30

• IP 67 Waterproof

• iOS, Android Apps

• 3500+ Cycles

• Advanced BMS

• Internal Heating

• Safe & Reliable

Description

• LiFePO4 Chemistry
• Group 8D Size (20.9" x 8.7" x 12.1") L x W x H
• 230Ah Capacity
• 230A Max Continuous Discharge (500A 30s Discharge)
• 230A Max Continuous Charge (400A 5s Charge)
• IP67 Rated, Dust and WATERPROOF
• HEATED - Internal heating for below 0C charging
• BLUETOOTH - iOS and Android Apps
• CANBUS Communication allows BMS to communicate directly with Victron OS
• Mountable ON/OFF Switch
• Mountable Battery gauge
• Built-in Smart Battery Management System (BMS)
• Internal fuse with current and temperature protections
• Over charge and over discharge protection
• Over current and short circuit protection
• High & low temperature disconnects
• 3500+ Cycle life & Maintenance-free
• 11 Year Manufacturer Warranty


Specification

CONFIGURATION

• Cell Configuration: 4S2P
• Chemistry: LiFePO4

CURRENT

• Ah Capacity: 230Ah
• Max Continuous Discharge Amps: 230A
• Max Charge Current Amps: 230A
• Max Discharge Peak Current Amps: 500A (30 Seconds) , 1300A (1 Second)
• Series | Parallel: Max (2) in Series OR Max (16) in Parallel - 2S1P or 1S16P

VOLTAGE

• Voltage: 25.6V
• Max Charge Voltage: 29.2V
• Operating Voltage Range: 20.0 - 29.2V

TEMPERATURE

• Charge Temp Range: -20°C (-4°F) / 55°C (131°F) (with heating)
• Discharge Temp Range: -20°C (-4°F) / 60°C (140°F)
• Storage Temp: 0°C (32°F) / 35°C (95°F)

Weight: 97 (LBS)
Dimensions
Length: 20.75 (inches)
Width: 8.5 (inches)
Height: 12 (inches)
