RELiON | RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D
RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D
The RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D is a powerful, long-lasting energy storage solution designed for marine, RV, solar, and off-grid applications. Engineered with advanced LiFePO4 (Lithium Iron Phosphate) technology, this battery delivers consistent voltage, superior safety, and exceptional efficiency—making it the perfect upgrade from traditional lead-acid batteries.
With its 100Ah capacity, lightweight construction, and built-in Battery Management System (BMS), the RB24V100 ensures reliable performance, extended cycle life, and peace of mind in demanding environments. Whether you’re powering a boat, RV, or renewable energy system, this battery is built to handle rugged use with maximum durability.
Key Features
-
High-Capacity Energy Storage – 24V 100Ah design supports extended power needs for marine, RV, and off-grid use
-
Long Cycle Life – Thousands of charge/discharge cycles for years of dependable service
-
Stable Power Output – Consistent voltage delivery for reliable system performance
-
Advanced Safety – Integrated BMS provides overcharge, over-discharge, and short-circuit protection
-
Lightweight & Efficient – Up to 50% lighter than comparable lead-acid batteries
-
Maintenance-Free – No watering, corrosion, or frequent upkeep required
-
Rugged Design – Shock and vibration resistant for harsh conditions
-
Eco-Friendly Chemistry – LiFePO4 contains no hazardous materials and is fully recyclable
Why Choose the RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D?
-
Provides more usable capacity compared to lead-acid batteries
-
Delivers faster charging and higher efficiency for modern energy systems
-
Perfect for marine, RV, solar, and off-grid power setups
-
Designed to maximize performance, safety, and longevity
Order the RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D Today
Upgrade your power system with the RB24V100 24V 100Ah Deep Cycle Lithium Battery – Group 8D and experience reliable, maintenance-free energy storage built for today’s demanding applications.
Shop now and enjoy longer runtimes, greater efficiency, and superior performance with the RB24V100.
Specifications
Electrical Specifications
- Nominal voltage: 25.6V
- Capacity: 100Ah
- Energy: 2560Wh
- Chemistry: Lithium Iron Phosphate (LiFePO4)
- Cycle life: 3500+ cycles at 80% depth of discharge
- Self-discharge: <3% per month
Discharge Specifications
- Max continuous discharge current: 100A
- Peak discharge current: 200A (7.5 ± 2.5 s)
Charge Specifications
- Recommended charge voltage: 28.4V – 29.2V
- Max charge current: 100A
Temperature Specifications
- Operating temperature (discharge): -4°F to 140°F (-20°C to 60°C)
- Operating temperature (charge): 32°F to 113°F (0°C to 45°C)
Mechanical Specifications
- Weight: 59.5 lbs (27 kg)
- Dimensions: Group 8D standard size (L x W x H)
- Terminal type: M8 bolt
- Waterproof rating: IP67
Compliance & Certifications
- CE, UKCA
- UN38.3 (battery)
- UL1642 (cells)
- IEC62133 (cells)
