RUiXU | Single-Phase Off-Grid Inverter | SUNON3.6 | 3.6kW | UL1741(PRE-ORDER)
RUiXU | Single Phase Off Grid Inverter SUNON3.6 3.6kW UL1741
Note: Pre-order ETA – End of November
The RUiXU SUNON3.6 Single-Phase Off-Grid Inverter delivers efficient and reliable power conversion for off-grid energy systems. With a 3.6kW output capacity and UL1741 certification, it ensures stable and safe operation for residential, commercial, and remote applications. Engineered for seamless integration with solar panels and battery storage, this inverter provides pure sine wave output, advanced protection features, and intelligent energy management for dependable off-grid performance
KEY FEATURES
-
Powerful Hybrid Charging
Supports charging up to 80A, combining solar and grid hybrid charging.
-
Intelligent Time-Sharing
Allows for timed charging and discharging, maximizing energy efficiency.
-
Stackable Design
Stack up to 6 units for a total output of 21.6kW
-
Rapid Shutdown
Quickly de-energizes solar PV systems to protect first responders
-
WiFi & App Integration
Connects via WiFi to an app for easy access and monitoring of information.
Specifications
| Category | Item | Specification |
|---|---|---|
| Inverter Output | Max. Output Power | 7,200 VA |
| Rated Output Voltage | 120 Vac | |
| Load Capacity (Motors) | 2 HP | |
| Rated Frequency | 50/60 Hz | |
| Output Wave | Pure Sine Wave | |
| Switching Time | 10 ms (typical) | |
| Battery | Battery Type | Lithium-ion / Lead-acid / User-defined |
| Rated Battery Voltage | 48 V | |
| Voltage Range | 40–60 VDC | |
| Max. Solar Charging Current | 80 A | |
| Max. Grid/Generator Charging Current | 40 A | |
| Max. Mixed Charge Current | 80 A | |
| Solar Input | No. of MPPT | 1 |
| Max. Input Power | 4,500 W | |
| Max. Input Current | 27 A | |
| Max. Open Circuit Voltage | 300 VDC | |
| MPPT Voltage Range | 90–260 VDC | |
| Grid/Generator Input | Input Voltage Range | 90–140 Vac |
| Input Frequency Range | 50/60 Hz | |
| Bypass Overload Current | 40 A | |
| Efficiency | MPPT Tracking Efficiency | 99% |
| Max. Overall Efficiency | 91% | |
| General Data | Parallel Capacity | 1–6 Units (2+ for Split-phase / 3+ for Three-phase) |
| Dimensions (L×W×H) | 16.85 × 12.99 × 4.33 in (428 × 330 × 110 mm) | |
| Weight | 17.86 lb (8.1 kg) | |
| Noise Level | < 60 dB | |
| Cooling Method | Intelligent Fan | |
| Protection Degree | IP20 (Indoor Only) | |
| Operating Temperature | -10°C to 55°C (Derate >45°C) | |
| Warranty | 3 Years | |
| Communication | RS485 / CAN / USB / Dry Contact | |
| External Module (Optional) | Wi-Fi / GPRS | |
| Integrated Circuit Breaker | — | |
| Certificate | FCC Part 15 Class B / UL1741 | |
| Protection & Recovery | Overload Protection | Output restores after 3 min; after 5 overloads, inverter shuts down until restarted (102–125%: error after 5s) |
