Victron Energy | Quattro 48/10000/140-100/100 120V VE.Bus (UL) Pure Sine Wave Inverter/Charger
Victron Quattro 48/10000/140-100/100 120V VE.Bus (UL) Pure Sine Wave Inverter/Charger
The Victron Quattro is a powerful, all-in-one inverter/charger system engineered for high-demand energy applications. Like the MultiPlus series, it combines a pure sine wave inverter, an advanced battery charger, and automatic transfer switch capabilities. The Quattro stands apart by offering two AC inputs, dual AC outputs, and full system integration support for complex installations including split-phase, three-phase, and parallel operation.
Key Features
Dual AC Inputs with Automatic Switching
-
Seamlessly connects to two independent AC sources (e.g., shore power and generator).
-
Automatically switches to the active input without manual intervention.
Two AC Outputs
-
Primary Output: Provides uninterruptible power (UPS functionality) with sub-20ms switchover—ensuring sensitive electronics like computers remain unaffected during transitions.
-
Secondary Output: Only live when AC input is available. Ideal for non-critical loads such as water heaters.
True Sine Wave Inverter
-
Delivers clean, stable 120V power suitable for all sensitive electronics and appliances.
PowerAssist & PowerControl
-
PowerControl: Prevents generator or grid overload by limiting charging current based on available supply.
-
PowerAssist: Supplements limited shore or generator power with battery energy during high-demand peaks.
Massive System Scalability
-
Configure in three-phase, split-phase, or parallel setups:
-
Up to 4 sets of 3 x 15 kVA units for a total of 144kW / 180kVA inverter capacity.
-
2400A combined charging capacity.
-
Solar Integration
-
Ideal for both off-grid and grid-connected solar PV systems.
-
Supports grid-tie inverters, MPPT charge controllers, and energy self-consumption applications.
Flexible Configuration & Monitoring
-
On-Site Setup: DIP switch programming or VE.Bus Quick Configure/System Configurator.
-
Remote Configuration & Monitoring: Through Color Control GX or other GX devices via Ethernet or Bluetooth.
-
Monitor and control systems via VRM (Victron Remote Management)—free online platform.
Comprehensive Monitoring Options
-
Compatible with Victron Battery Monitor, Multi Control Panel, Color Control GX, smartphones, tablets, laptops, and PCs.
Specification
| Model | Battery Voltage (V) | Power (VA) | Cont. Power 25°C (W) | Cont. Power 40°C (W) | Cont. Power 65°C (W) | Peak Power (W) | Max Efficiency (%) | Charge Current (A) | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| 12/3000 | 12 | 3000 | 2400 | 2200 | 1700 | 6000 | 93 | 120 | 19 | 362 x 258 x 218 |
| 24/3000 | 24 | 3000 | 2400 | 2200 | 1700 | 6000 | 94 | 70 | 19 | 362 x 258 x 218 |
| 12/5000 | 12 | 5000 | 4000 | 3700 | 3000 | 10000 | 94 | 220 | 34 | 470 x 350 x 280 |
| 24/5000 | 24 | 5000 | 4000 | 3700 | 3000 | 10000 | 95 | 120 | 30 | 470 x 350 x 280 |
| 48/5000 | 48 | 5000 | 4000 | 3700 | 3000 | 10000 | 96 | 70 | 30 | 470 x 350 x 280 |
| 24/8000 | 24 | 8000 | 6400 | 5500 | 3600 | 16000 | 94 | 200 | 45 | 444 x 328 x 240 |
| 48/8000 | 48 | 8000 | 6400 | 5500 | 3600 | 16000 | 96 | 110 | 41 | 444 x 328 x 240 |
| 48/10000 | 48 | 10000 | 8000 | 6500 | 4500 | 20000 | 96 | 140 | 51 | 470 x 350 x 280 |
| 48/15000 | 48 | 15000 | 12000 | 10000 | 7000 | 25000 | 96 | 200 | 72 | 572 x 488 x 344 |
